MUBO

MGA FEATURES

• With a 25-ton capacity, it is designed to handle large volumes of waste. This makes it ideal for use in urban areas with high waste generation or in industrial settings.
• The electric power source provides a clean and sustainable alternative to traditional fuel-powered trucks. It reduces emissions and noise pollution, making it more environmentally friendly.

• The rear compactor is a key feature of this truck. It is designed to efficiently compress waste, maximizing the load capacity and reducing the number of trips required for waste disposal.
• The compaction system is powerful and reliable, capable of handling a wide variety of waste materials, including solid waste, recyclables, and bulky items.

• The truck is equipped with advanced technology to enhance its performance and efficiency. This may include features such as intelligent control systems, real-time monitoring, and remote diagnostics.
• Some models may also have features such as automatic loading and unloading, which can further streamline waste management operations.

• Built with high-quality materials and components, the Dongfeng 25 Ton Electric Rear Compactor Truck is designed to withstand the rigors of daily use. It has a sturdy chassis and a durable body that can resist corrosion and damage.
• Regular maintenance is made easy with accessible components and a user-friendly design. This helps to ensure long service life and minimal downtime.

• Safety is a top priority, and this truck is equipped with a range of safety features to protect operators and the public. These may include features such as anti-lock brakes, pagkontrol sa kalig-on, and backup cameras.
• The compactor mechanism is also designed with safety in mind, with features such as safety locks and emergency stop buttons.

• The truck can be used in a variety of waste management applications, including residential, commercial, and industrial waste collection. It can also be adapted to different waste types and disposal methods.
• Optional attachments and features can be added to customize the truck for specific needs, further enhancing its versatility.

ESPESPIKASYON

Batakang Impormasyon
Porma sa pagmaneho	6X4
Wheelbase	4700+1350mm
Ang gitas-on sa lawas	8.48 metros
Kalapad sa lawas	2.5 metros
Taas sa lawas	3.055 metros
Timbang sa sakyanan	14.33 tonelada
Rated load	10.475 tonelada
Kinatibuk-ang masa	25 tonelada
Kinatas-ang tulin	85km/h
Factory standard range	420km
Motor
Brand sa motor	Jingjin
Modelo sa motor	TZ460XSF06
Type sa motor	Permanent magnet synchronous drive motor
Gi-rate nga gahum	143kW
Kinatas-ang gahum	220kW
Mounted equipment parameters
Vehicle type	Electric Rear Compactor Truck
Special function description	Production enterprise： Xiongchuan Hydrogen Energy; Fuel cell form： Proton exchange membrane fuel cell; Peak power of fuel cell： 94kW; Hydrogen storage volume： 1328L; This vehicle is made by selecting the chassis with a wheelbase of 4700+1350 or 4300+1350mm, and is equipped with a self-unloading cargo box and hydraulic cylinders (optional models). The cargo box is strong and wear-resistant, the system is flexible in operation, has strong transportation capacity, and is environmentally friendly. Electronic control model： KTZ62X62SF06; Electronic control mode： Vector control; Electronic control cooling method： Liquid cooling
Mga parameter sa kab
Ang Cab	Dongfeng Huashen T7
Mga parameter sa chassis
Chassis series	Dongfeng Huashen T7
Chassis model	EQ1250GTZFCEVJ
Number of leaf springs	September 9th
Front axle load	7000KG
Rear axle load	18000 (duha ka axle nga grupo) KG
Mga ligid
Pagtino sa ligid	11.00R20LT 18PR
Gidaghanon sa mga ligid	10 pieces
Baterya
Brand sa baterya	CATL
Battery model	L092C04
Matang sa baterya	Lithium iron phosphate nga baterya
Kapasidad sa baterya	47.69kWh
Energy density	116.05Wh/kg
Brand of electronic control system	Jingjin Technology
