SUMMARY
FEATURES
SPECIFICATIONS
Basic Information | |
Drive form | 4X2 |
Wheelbase | 2800mm |
Vehicle length | 5.3 meters |
Vehicle width | 1.86 meters |
Vehicle height | 2 meters |
Vehicle weight | 2.5 tons |
Rated load | 1.67 tons |
Total mass | 4.3 tons |
Maximum speed | 90km/h |
CLTC cruising range | 280km |
Motor | |
Motor brand | CRRC Times Electric |
Motor model | TZ220XS504 |
Motor type | permanent magnet synchronous motor |
Rated power | 60kW |
Peak power | 140kW |
Motor rated torque | 110N·m |
Peak torque | 290N·m |
Mounted equipment parameters | |
Vehicle type | pure electric detachable garbage truck compartment |
Mounted equipment brand | Chengli brand |
Special function description | Collection and transportation of urban environmental sanitation garbage |
Cab parameters | |
Cab | single row, non-tilting |
Transmission parameters | |
Transmission model | automatic transmission |
Chassis parameters | |
Chassis series | Dongfeng Huashen |
Chassis model | EQ1040TTZEVJ1 |
Number of leaf springs | 3/5, 6/7+4 |
Front axle load | 1130kg |
Rear axle load | 2365kg |
Tires | |
Tire specification | 185R14LT 6PR |
Number of tires | 6 |
Battery | |
Battery brand | Lishen |
Battery model | LS1P50S-202Ah |
Battery type | lithium iron phosphate battery |
Battery capacity | 64.64kWh |
Energy density | 136.6Wh/kg |
Battery rated voltage | 320V |
Charging method | DC charging, AC charging |
Charging time | DC charging 2h, AC charging 6-8h |
Brand of electric control system | Jingjin Powe |
