SUMMARY
VEIKA LEVU
SPECIFICATIONS
iTukutuku Taumada | |
Fomu ni draiva | 4X2 |
Wheelbase | 2850mm |
Vehicle length | 4.72 mita |
Vehicle width | 1.8 mita |
Vehicle height | 2.02 mita |
Vehicle weight | 2.25 tani |
Rated load | 1.115 tani |
Total mass | 3.495 tani |
Totolo levu duadua | 90km/h |
CLTC cruising range | 250km |
Motoka | |
Brand ni motoka | CRRC Times Electric |
Motor model | TZ190XSZ |
Motor type | permanent magnet synchronous motor |
Rated power | 40kW |
Peak power | 80kW |
Motor rated torque | 110N·m |
Peak torque | 300N·m |
Mounted equipment parameters | |
Vehicle type | pure electric dump-type garbage truck |
Mounted equipment brand | Chengli brand |
Special function description | Collection and transportation of urban environmental sanitation domestic waste |
Cab parameters | |
Tekisi | Single row, non-tilting |
Transmission parameters | |
Transmission model | Automatic transmission |
Chassis parameters | |
Chassis series | Dongfeng Xianglv |
Chassis model | EQ1030CACEV |
Number of leaf springs | 6/7+4 |
Front axle load | 1130kilo |
Rear axle load | 2365kilo |
Tires | |
Tire specification | 185R14LT 6PR |
Number of tires | 6 |
Bateri | |
Battery brand | BAK |
Battery model | 59P104S |
Battery type | ternary nickel cobalt manganese lithium composite battery |
Levu ni bateri | 53kWh |
Energy density | 130Wh/kg |
Battery rated voltage | 374.4V |
Total battery voltage | 431.6V |
Charging method | DC fast charging, AC slow charging |
Charging time | DC fast charging 2h, AC slow charging 6-8h |
Brand of electric control system | Chongqing Kerry Power |
