BRIEF
EIGINLEIKAR
SPECIFICATION
Grunnupplýsingar | |
Hjólhaf | 3450mm |
Vehicle Length | 5.265m |
Vehicle Width | 1.87m |
Vehicle Height | 2.06m |
Gross Vehicle Mass | 3.15 tonn |
Metið burðargeta | 1.33 tonn |
Þyngd ökutækis | 1.69 tonn |
Front Overhang/Rear Overhang | 0.75/1.065m |
Hámarkshraði | 90km/klst |
CLTC Driving Range | 210km |
Rafmótor | |
Motor Brand | Lingdian |
Motor Model | TZ210XS00A&KTZ35X32S00A |
Tegund mótor | Permanent Magnet Synchronous Motor |
Málkraftur | 35kW |
Peak Power | 70kW |
Rated Torque of the Motor | 90N·m |
Peak Torque | 220N·m |
Fuel Type | Hreint rafmagn |
Færibreytur stýrishúss | |
Fjöldi sætisraða | 1 |
Rafhlaða | |
Rafhlaða vörumerki | EVE Energy |
Battery Model | LF125 |
Tegund rafhlöðu | Lithium – ion Storage Battery |
Rafhlöðugeta | 41.86kWh |
Energy Density | 136.2Wh/kg |
Total Battery Voltage | 334.88V |
Hleðsluaðferð | Fast Charging + Slow Charging |
Charging Time | 1.5h |
Brand of the Electronic Control System | Kama Brand |
Vehicle Body Parameters | |
Vehicle Body Structure | Load – bearing |
Number of Seats | 2 |
Carriage Parameters | |
Maximum Depth of the Carriage | 3.225m |
Maximum Width of the Carriage | 1.705m |
Carriage Height | 1.38m |
Carriage Volume | 8 cubic meters |
Chassis Steering | |
Front Suspension Type | Independent Suspension |
Rear Suspension Type | Leaf Spring |
Power Steering Type | Electric Power Steering |
Door Parameters | |
Number of Doors | 2 |
Side Door Type | Double – sided Sliding Doors |
Tailgate Type | Double – opening Doors |
Wheel Braking | |
Front Wheel Specification | 195/70R15LT |
Rear Wheel Specification | 195/70R15LT |
Front Brake Type | Diskabremsa |
Rear Brake Type | Trommubremsa |
Handling Configurations | |
ABS andstæðingur – lock Braking System | ● |
Internal Configurations | |
Steering Wheel Material | Plastic |
Fjölbreytt – function Steering Wheel | ○ |
Loft – conditioning Adjustment Mode | Handbók |
Power Windows | ● |
Electrically Adjustable Rear – view Mirrors | ● |
Heated Rear – view Mirrors | ● |
Reverse Image | ● |
Reverse Radar | ● |
Multimedia Configurations | |
GPS/BeiDou Vehicle Travel Recorder | ● |
Bluetooth/Car Phone | ● |
External Audio Source Interface (AUX/USB/iPod, etc.) | ● |
Lighting Configurations | |
Dagljós | ● |
Adjustable Headlight Height | ● |
Intelligent Configurations | |
Cruise Control | ○ |
