SPECIFICATION
ಮೂಲಭೂತ ಮಾಹಿತಿ | |
ಗಾಲಿ ಬೇಸ್ | 3050ಮಿಮೀ |
Vehicle Length | 4.865 ಮೀಟರ್ |
Vehicle Width | 1.715 ಮೀಟರ್ |
Vehicle Height | 2.06 ಮೀಟರ್ |
Gross Vehicle Mass | 3.15 ಟನ್ |
Rated Load Capacity | 1.4 ಟನ್ |
Vehicle Weight | 1.62 ಟನ್ |
Front Overhang/Rear Overhang | 0.75 / 1.065 ಮೀಟರ್ |
Maximum Speed | 90ಕಿಮೀ/ಗಂ |
CLTC Driving Range | 260ಕಿಮೀ |
Electric Motor | |
Motor Brand | Aosweier |
Motor Model | TZ200XS60K |
Motor Type | Permanent Magnet Synchronous Motor |
Rated Power | 30ಒಂದು |
Peak Power | 60ಒಂದು |
Rated Torque of the Motor | 90N · m |
Peak Torque | 220N · m |
Fuel Type | Pure Electric |
ಬ್ಯಾಟರಿ | |
Battery Brand | Lishen |
Battery Type | Lithium Iron Phosphate Lithium-ion |
Battery Capacity | 41.6kWh |
Energy Density | 135Wh/kg |
Charging Method | Fast Charging + Slow Charging |
Charging Time | 0.8h for Fast Charging (80%), 13h for Slow Charging |
Vehicle Body Parameters | |
Number of Seats | 2 seats |
Carriage Parameters | |
Maximum Depth of the Carriage | 2.65 ಮೀಟರ್ |
Maximum Width of the Carriage | 1.55 ಮೀಟರ್ |
Carriage Height | 1.35 ಮೀಟರ್ |
Carriage Volume | 5.4 cubic meters |
Chassis Steering | |
Front Suspension Type | Independent Suspension |
Rear Suspension Type | Leaf Spring |
Door Parameters | |
Side Door Type | Manual Sliding Door |
Tailgate Type | Double-opening Door |
Wheel Braking | |
Front Wheel Specification | 195R14C 8PR |
Rear Wheel Specification | 195R14C 8PR |
Front Brake Type | Disc Brake |
Rear Brake Type | Drum Brake |
Safety Configurations | |
Seat Belt Unfastened Warning | ● |
Remote Control Key | ● |
Vehicle Central Lock | ● |
Handling Configurations | |
ABS Anti-lock Braking System | ● |
Internal Configurations | |
Air Conditioning Adjustment Mode | ಪ್ರಮಾಣಕ |
Power Windows | ● |
Reverse Image | – |
Reverse Radar | ○ |
Multimedia Configurations | |
Bluetooth/Car Phone | – |
External Audio Source Interface (AUX/USB/iPod, etc.) | ● |
Lighting Configurations | |
Front Fog Lights | ● |
