BRIEF
XUSUSIYATLARI
SPECIFICATION
Asosiy ma'lumotlar | |
E'lon modeli | DLP5011XLCBEVD01 |
Drive form | 4X2 |
G'ildirak bazasi | 2200mm |
Body length | 3.3 metr |
Body width | 1.08 metr |
Body height | 1.95 metr |
Avtotransportning og'irligi | 0.635 tonnani tashkil etadi |
Yuqori darajadagi yuk | 0.245 tonnani tashkil etadi |
Umumiy massa | 0.945 tonnani tashkil etadi |
Maksimal tezlik | 71km/soat |
Kelib chiqishi | Anyang, Henan |
Factory-standard cruising range | 120km |
Yoqilg'i turi | Sof elektr |
Dvigatel | |
Motor brendi | OSWELL |
Motor modeli | TZ160X12A |
Motor turi | Doimiy magnit sinxron motor |
Cho'qqisi | 12kVt |
Rated torque of the motor | 10N·m |
Yoqilg'i toifasi | Sof elektr |
Cargo box parameters | |
Cargo box length | 1.54 metr |
Cargo box width | 0.93 metr |
Cargo box height | 0.91 metr |
Mounting parameters | |
Refrigeration unit | Bingxiong, Xinfei, Xileng, Bonuoer |
Chassis parameters | |
Chassis series | Dali King of the Ox |
Chassis model | DLP1011BEVD01 |
Number of leaf springs | -/3 |
Front axle load | 373KG |
Rear axle load | 572KG |
Shinalar | |
Tire specification | 135/70 R12 |
Number of tires | 4 |
Batareya | |
Batareya markasi | Guoxuan High-Tech |
Batareya turi | Litiy temir fosfat |
Battery capacity | 9.98kVt/soat |
Energy density | 114Wh/kg |
Total battery voltage | 96V |
